Technical parameters |
|---|
| Length of the working table |
850 mm |
| Width of the working table |
410 mm |
| Maximum table load (evenly distributed) |
300 kg |
| Minimum rotary speed of the vertical spindle |
100 1/min |
| Maximum rotary speed of the vertical spindle |
10000 1/min |
| Minimum distance of the spindle from the table |
150 mm |
| Maximum distance of the spindle from the table |
480 mm |
| Travel length X-axis (mechanical feed) |
700 mm |
| Travel length Y-axis (mechanical feed) |
400 mm |
| Travel length Z-axis (mechanical feed) |
330 mm |
| Maximum feed rate in X-axis |
900 mm/s |
| Maximum feed rate in Y-axis |
900 mm/s |
| Maximum feed rate in Z-axis |
900 mm/s |
| Number of T-slots in the table |
3 pcs |
| Machine length |
2165 mm |
| Machine width |
2040 mm |
| Machine weight |
2.2 t |
