Technical parameters |
|---|
| Length of the working table |
850 mm |
| Width of the working table |
260 mm |
| Number of rotary speeds of the spindle |
12 pcs |
| Minimum rotary speed of the spindle |
50 1/min |
| Maximum rotary speed of the spindle |
2240 1/min |
| Travel length X-axis (mechanical feed) |
560 mm |
| Travel length Y-axis (mechanical feed) |
220 mm |
| Travel length Z-axis (mechanical feed) |
360 mm |
| Maximum feed rate in X-axis |
56.7 mm/s |
| Maximum feed rate in Y-axis |
56.7 mm/s |
| Maximum feed rate in Z-axis |
28.3 mm/s |
| Power of the spindle drive |
3 kW |
| Machine height |
1530 mm |
| Machine length |
1600 mm |
| Machine width |
1900 mm |
| Machine weight |
1.3 t |
